Superior Solution for Shaft Connections in Large Bore Applications
Traditional large cast iron couplings, commonly utilized to connect shafts in various heavy-duty applications such as lumber, steel, rail, recycling, and paper industries, are typically manufactured from iron and are known for their substantial weight.
![Rail Rail](/wp-content/uploads/Rail-768x600-1.png)
Conventional large cast iron couplings feature a bulky design, necessitating extra space to accommodate their oversized outer diameter. The sheer size of these antiquated couplings places undue stress on the shaft and increases the risk of damaging both the shaft and its associated components. Likewise, to achieve the necessary torque for these applications, cast iron couplings rely on a keyway, leading to issues such as wallowing, backlash, fretting corrosion, and fatigue failure, all commonly associated with keyways.
Maintaining Component Integrity in Wastewater Treatment Plants
Climax Shrink Disc style flanged couplings in lieu of bore-keyway-setscrew or interference fits, allows for stronger shafts while eliminating corrosion sites and stress risers that are a common point of failure.
Mounting couplings with traditional keyed connections in treatment applications such as clarifier drives and drag conveyors introduces several compromises. Whenever a shaft is keyed, it must be oversized to account for the loss of effective cross section. This adds weight and cost not only to the shaft, but to every component on the shaft. Once assembled, keyways are at risk of corrosion build up resulting in backlash and fretting. In wastewater applications where slow rotation requires a greater torque, keyways produce a great risk for timing issues, resulting in downtime and loss of profit. Climax KLDs eliminate the need for keyways reducing the risk of corrosion, providing a longer life for clarifier drives and drag conveyors.
Using a press or shrink fit method, while effective (more…)
